Tekniska data
| Max belastn vertikalt (Load vert) | 2500 kg |
|---|---|
| Max belastn horisontalt (Load Hori) | 2500 kg |
| Rotationshastighet (Rotary speed) | 0,05-1,6 r/min |
| Vridmoment (Turning Moment) | 2500 Nm |
| Tippmoment (Overturning Moment) | 6500 Nm |
| Bordsplattans diameter (Plate dim) | 800 mm |
| Min-max höjd (Min-Max Hight) | 650-1640 mm |
| Nätanslutning (Power Supply) | 400 V |
| Vikt (Weight) | 1250 kg |
| Längd (Length) | 2400 mm |
| Bredd (Width) | 1200 mm |
| Höjd (Hight) | 650 mm |
