Tekniska data
| Max belastn vertikalt (Load vert) | 16000 kg |
|---|---|
| Max belastn horisontalt (Load Hori) | 16000 kg |
| Rotationshastighet (Rotary speed) | 0,03 – 0,7 r/min |
| Vridmoment (Turning Moment) | 16000 Nm |
| Tippmoment (Overturning Moment) | 80000 Nm |
| Bordsplattans diameter (Plate dim) | 1600 mm |
| Min-max höjd (Min-Max Hight) | 1100 – 2450 mm |
| Nätanslutning (Power Supply) | 400 V |
| Vikt (Weight) | 7500 kg |
| Längd (Length) | 4500 mm |
| Bredd (Width) | 2400 mm |
| Höjd (Hight) | 1200 mm |
